| Technical Data |
Cutting capacity(mm) |
650mm for Round shape, 650WX650H for square shape |
| Blade speed(m/min) |
25/40/65 |
| Blade size(mm) |
1.6×54 |
| Main Motor(kw) |
5.5 |
| Hydraulic Motor(kw) |
1.5 |
| Work piece Clamping |
Hydraulic Vise |
| Blade Tension |
Manual |
| Main Drive |
Worm wheel drive |
| Material feed |
Manual |
| Machine size |
3300×2000×2100 |
| Machine weight |
3500kg |
| Standard Equipment |
Blade cleaning brush |
Power blade cleaning brush |
| Working light |
YES |
| One piece of bi-metal saw blade |
YES |
| One set of tools with tool box |
YES |
| Operation manual |
YES |
| Manual work height control |
YES |
| Machine package |
Steel and plywood |
|---|
| Option parts |
1. Hydraulic blade tension |
| 2. 1.5m Electric Motor Roller table |
3. Band saw blade |
| 4. Inverter speed |
5. Chip conveyor |
